X5042 vertical milling head

Manual knee type machine, vertical milling head, rigidity structure
CategoriesManual Milling Machine
BrandZOPO INTELLIGENT EQUIPMENT MACHINING CENTER OEM
ModelX5042
BRANDZOPO CNC
CONTROLMANUAL
SPINDLEVERTICAL MILLING HEAD
Update TimeDec 10,2024
Detail Information

X5042

 KNEE TYPE MILLING MACHINE

X5042

1200/360/470mm

X/Y/Z axis travel


420×1800mm

Worktable size


1500rpm

Spindle speed


2400/2400/900mm/min

Rapid feed speed

  • Model
  • Appearance
  • Characteristics
  • Parameters
  • Contact Us
Appearance
X5042
Characteristics
结构钢性

Rigidity structure +Stability precision


This vertical knee type milling machine has high rigidity structure and stable precision. .Three direction of guideways have adopted wear-resistant measuresment to maintain high accuracy and long life.
加工应用能力

Extensive Application


Mounted with rod, disc, angle, forming and face milling cutter, the machine can use for flat, bevel, angle, groove and edge processing. The machine can also be milling gears, reamers, spiral grooves, cams and drums instal with indexing accessories and others, which is widely used in machining industries.
Parameters

Working range


Unit

X/Y/Z axis travel
1200/360/470mm
Distance from spindle nose to table surface
40-510 mm
Distance from spindle center to vertical guideway
450mm
Distance from table center to vertical guideway
275-655 mm

Worktable

Unit

Worktable size

420x1800mm
T slots

3-18*90mm
Max. load bearing of worktable
800kg

Spindle


Unit

Spindle hole taper
7:24 No.50
Spindle power
11KW
Max. spindle speed
1500rpm

Feed

Unit

Rapid feed speed
2400/2400/900mm/min
Feed speed range
22-1100/22-1100/8.3-410mm/min

Machine

Unit

Machine dimension

2522/2265/2432mm
Machine weight
4450kg
