X6142 Horizontal Miling Arbour Rotary Worktable

Manual knee type machine, horizontal arbour, rotary worktable, rigidity structure, stability precision
CategoriesManual Milling Machine
BrandZOPO INTELLIGENT EQUIPMENT MACHINING CENTER OEM
ModelX6142
BRANDZOPO CNC
CONTROLMANUAL
SPINDLEHORIZONTAL ARBOUR
Update TimeDec 10,2024
Detail Information

X6142

KNEE TYPE MILLING MACHINE

X6142

1200/360/470mm

X/Y/Z axis travel


420×1800mm

Worktable size

1500rpm

Spindle speed


2400/2400/900mm/min

Rapid feed speed

  • Model
  • Appearance
  • Characteristics
  • Parameters
  • Contact Us
Appearance
X6142
Characteristics
结构钢性

Rigidity structure +Stability precision


This horizontal knee type milling machine has high rigidity structure and stable precision. .Three direction of guideways have adopted wear-resistant measuresment to maintain high accuracy and long life.
加工应用能力

Extensive Application


Mounted with rod, disc, angle, forming and face milling cutter, the machine can use for flat, bevel, angle, groove and edge processing. The machine can also be milling gears, reamers, spiral grooves, cams and drums instal with indexing accessories and others, which is widely used in machining industries.
Parameters

Working range


Unit

X/Y/Z axis travel
1200/360/470 mm
Distance from spindle nose to table surface
40-500 mm
Distance from spindle center to vertical guideway
200 mm
Distance from table center to vertical guideway
280-650 mm

Worktable


Unit

Worktable size
420x1800mm
T slots
3-18*90mm
Max. load bearing of worktable
800kg

Spindle

Unit

Spindle hole taper
7:24 No.50
Spindle power
11KW
Max. spindle speed
1500rpm

Feed

Unit

Rapid feed speed
2400/2400/900mm/min
Feed speed range
22-1100/22-1100/8.3-410mm/min

Machine

Unit

Machine dimension
2522/2262/2047mm
Machine weight
4200kg
